Antistatic HPL Tile

Product Overview

Antistatic HPL tile is the walking surface of a raised access floor: a high-pressure laminate face cut to panel size and bonded into the panel rebate, so the finished floor reads as one continuous surface while each panel can still be lifted for cable work. It is supplied for new build and retrofit projects where static control and a hard-wearing walking surface both matter. The laminate is pressed rather than coated, which is why it holds up under the constant panel lifting on a busy floor.

Why Specifiers Choose This Surface

• Pressed construction — resin-impregnated layers are pressed into one dense sheet, so there is no thin film to peel away or wear through in patches.
• Static control as standard — the surface is supplied as an ESD conductive tile for rooms where a discharge from a person, trolley or test instrument could reach sensitive electronics.
• Stable in warm, dry halls — data center air stays warm and dry all year, and the laminate is specified for how it holds shape in that environment rather than for decoration.
• Closely controlled thickness — tiles are cut to your panel format, so joint lines stay tight and neighbouring panels sit level.
• Consistent resurfacing option — raised flooring manufacturers often choose a hard laminate face when panels are lifted frequently for cabling and airflow work.

Thickness & Panel Fitting

• 1.0 mm (±0.15 mm) — thinnest face, for shallow machined rebates where the tile must sit close to flush.
• 1.2 mm (±0.15 mm) — middle option with more material for aisles that see trolley and cart traffic all day.
• 1.5 mm (±0.15 mm) — thickest face, for floors that are lifted and re-laid often or where panels are resurfaced instead of replaced.
• Measure the rebate, not the old tile — work from the panel face down to the recess floor; a worn tile can measure thinner than the rebate really is.
• Cut for standard panel formats — raised access floor tiles are supplied in the size you give us, including radius corners, so each one matches the rebate the panel was machined with.
• Distributors and commercial flooring suppliers can order by the thickness and finish they move most often, quoted with the rest of the floor package.

Where This Tile Is Used

Static-controlled raised floors are the main setting. Data center white space and hot aisles use this surface because panels are lifted constantly for cabling and airflow work. Computer rooms, telecom switch rooms and control rooms follow the same pattern, with the same need for a hard surface that resists scuffs from repeated access. Electronics assembly and test areas rely on it to protect boards and instruments during handling. Laboratories and production areas where equipment carts roll over the same route all day are another common setting. Commercial flooring suppliers also hold stock for retrofit jobs where existing panels need a new face rather than a full replacement.

Scale & Supply Capability

As a raised access flooring supplier, we cover a complete system rather than single items: pedestals and stringers, antistatic PVC and HPL tiles, PVC skirting, panel lifters and cutting blades, air diffusers, brush grommets, flip outlet boxes and in-floor cooling units. Our structural components suit OA, steel, wood core, calcium sulphate and aluminium raised floors, with pedestal heights from 70 to 1500 mm. Specifications such as stringer size and thickness can be customised to your project, so contractors can source compatible components, installation tools and cooling accessories from one supplier for data center, computer room and commercial fit-outs.
