Antistatic Calcium Sulphate Raised Access Floor

Functional Compatibility for Technical Environments

The Antistatic Calcium Sulphate Raised Access Floor is engineered specifically for high-demand technical spaces such as data centers, electronic workshops, and monitoring centers. Optimized for environments requiring stringent static control, this system provides a stable platform tailored for sensitive equipment and critical infrastructure. Its flexible pedestal height adjustment from 70 to 1500 mm enables customized underfloor configurations, supporting diverse cabling, ventilation, and equipment layouts. Target users include facility managers and system integrators responsible for server room flooring and raised computer room floors, ensuring precise static management and operational reliability across complex technical workflows.

Advanced Material Composition and Load-bearing Specifications

Constructed with purified calcium sulphate reinforced by eco-friendly plant fibers, this access flooring solution delivers robust antistatic and fire-retardant properties critical to controlled environments. The modular panel size of 600 × 600 mm and adjustable thickness between 25 and 38 mm maintain exceptional flatness and shock resistance under heavy rack installations. Load capacities vary across FS800 to FS1500 models, accommodating concentrated loads up to ≥6700 N and uniform loads up to ≥34500 N/m², supporting even the most demanding server room raised floor requirements. The system’s steel pedestal framework allows fine-tuned height modulation facilitating systematic underfloor airflow and cable distribution critical to comprehensive infrastructure integrity.

Sector-specific Utility Across Critical Facilities

This raised floor solution integrates seamlessly within sectors requiring rigorous environmental control, including data centers, cleanrooms, and electronic manufacturing facilities. It supports infrastructure expansion and retrofit projects needing dependable static dissipation and fire safety compliance. By providing stable, uniform surfaces with recyclable, durable materials, it reduces long-term lifecycle costs and maintenance disruptions. The system also accommodates complex underfloor workflows involving power and data distribution pathways essential for modern server room flooring configurations and raised access floor manufacturers seeking proven, long-term infrastructure versatility.

 Product Advantages

Structural and Design Advantages in Modular Systems

The design of this antistatic raised access floor prioritizes modularity and adaptability through standardized 600 × 600 mm panels and height-adjustable die-cast steel pedestals, suitable for various technical environments. This structural system supports integration with underfloor air handling units, cabling ducts, and equipment access points, making it a preferred choice among raised access floor manufacturers. Its calcium sulphate core reinforced with plant fibers offers elevated fire-retardant properties while maintaining panel flatness and dimensional stability, ensuring the system withstands dynamic loads without deformation. Such design considerations enable rapid installation, efficient maintenance scheduling, and streamlined scalability for evolving server room flooring needs.

Performance Reliability and Operational Efficiency Benefits

The antistatic and fire-retardant characteristics of this raised floor solution provide consistent static dissipation essential to protecting sensitive hardware common in raised computer room floors. Its load rating spectrum—ranging from FS800 to FS1500 models—supports heavy traffic and rack installations with superior impact resistance and rolling load capacities, enhancing operational safety and longevity. Easy panel replacement capabilities reduce downtime during maintenance or system upgrades, fostering workflow continuity. The floor’s compatibility with underfloor cooling and power/data distribution systems increases infrastructure efficiency and user confidence, crucial in mission-critical applications such as network service rooms and monitoring centers.

Characteristic

Environmentally friendly

Antistatic, fireproof, high loading capacity, flatness and shockproof

Adjustable height for pedestal, assembly agility, large wire and good exchangeability

Elegant appearance for various top tiles

Stable performance in humidity& temperature

Recyclable, convenient removing, cost saving, long performance life

Die casting steel structure pedestal, plastic gasket on top, height could be 70-1500mm, with or no square tube stringer

Application

All kinds of computer room, network service room, monitoring center, electronic workshop, clean room, dustless chamber etc, and occasions demanding antistatic and air conditioning

Technical Specification

Size: 600*600mm

Thickness: 25~38mm

 Use Scenarios

Data Center Infrastructure Enhancement

In data center environments, the Antistatic Calcium Sulphate Raised Access Floor functions as a foundational element enabling precise static control and robust load handling capacity. It supports extensive underfloor cable management and airflow systems required for high-density server racks and networking equipment. The product’s fire-retardant core and superior flatness align with industry compliance standards, safeguarding critical hardware from electrostatic discharge and fire hazards. It also facilitates efficient integration with power distribution and cooling subsystems, enhancing energy efficiency and serviceability. Facility engineers rely on this system to maximize uptime, simplify maintenance, and optimize thermal management within complex raised floor solutions.

Electronic Workshop and Cleanroom Flooring Applications

This raised floor system is well-suited for electronic manufacturing workshops and controlled cleanroom environments where antistatic properties and fire safety are paramount. Its material composition ensures dimensional stability despite humidity and temperature fluctuations inherent in these facilities. The modular panel design allows for flexible configuration and rapid access to underfloor utilities, ensuring uninterrupted production workflows and compliance with strict environmental regulations. Users benefit from improved operational safety and ease of reconfiguration during technological upgrades while accommodating cabling, ventilation, and equipment access needs integral to contemporary access flooring practices.

FAQ

What materials are used in your Antistatic Calcium Sulphate Raised Access Floor?

We use purified calcium sulphate reinforced with eco-friendly plant fibers to manufacture our raised floor solutions. This composition provides essential antistatic and fire-retardant properties, ensuring reliable performance for sensitive environments like data centers and server rooms.

Can I customize the pedestal height for specific project requirements?

Yes, our raised access floor system features fully adjustable die-cast steel pedestals with a height range from 70 to 1500 mm. This flexibility enables precise underfloor space management for cabling, ventilation, and equipment access tailored to your project needs.

How do you ensure the durability and stability of your raised computer room floors?

Our raised floors maintain excellent flatness and shock resistance under dynamic loads, even with humidity and temperature fluctuations. This consistent performance supports long-term operational stability and safety in demanding technical spaces like server rooms and cleanrooms.

Do you provide support for installation and maintenance of access flooring?

We design our modular panel system for straightforward installation, maintenance, and panel replacement. As experienced raised access floor manufacturers, we also offer technical consultation to optimize your floor system’s integration with underfloor airflow, power, and data distribution.
